Product Overview
The TESTech Alcohol Burner Combustion Tester is designed, developed, and manufactured according to MT182.
It is suitable for alcohol burner combustion tests under laboratory conditions for non-metallic products used in underground coal mines.
Picture is for reference only.
Technical Features
- Simultaneously complies with the requirements of MT141, MT914, and MT182.
- Cabinet is made of stainless steel.
- Supplied with flame temperature calibration package and flame height gauge.
- Graduated side arm with minimum scale of 0.1 mL.
- Push-pull burner structure.
- Timing accuracy up to 0.01 s.
- Equipped with alcohol burner and alcohol injection piping.
- Equipped with drain valve for easy discharge of remaining alcohol.
- Combustion chamber size: 660 mm x 660 mm x 1050 mm.
- Overall machine size: 910 mm x 660 mm x 1050 mm.
- Transparent observation door and exhaust fan are provided.
- Touch screen intelligent control with automatic timing and automatic average calculation.
- Test reports can be retrieved freely.
Technical Summary
|
Parameter |
Value |
|
Applicable Standards |
Simultaneously complies with MT141, MT914, and MT182 |
|
Chamber Material |
Combustion chamber made of stainless steel |
|
Calibration Kit |
Supplied with flame temperature calibration package and flame height gauge |
|
Graduated Side Arm |
Minimum scale 0.1 mL |
|
Burner Structure |
Push-pull burner structure |
|
Timing Accuracy |
Up to 0.01 s |
|
Alcohol Supply |
Equipped with alcohol burner and alcohol injection piping |
|
Drain Valve |
Equipped with drain valve for easy discharge of remaining alcohol |
|
Combustion Chamber Size |
660 mm x 660 mm x 1050 mm |
|
Overall Dimensions |
910 mm x 660 mm x 1050 mm |
|
Observation Door |
Transparent observation door and exhaust fan |
|
Control System |
Touch screen intelligent control, automatic timing, and automatic average calculation |
|
Report Handling |
Test reports can be retrieved freely |
