Product Overview
The TESTech Hard Casing Retardant Performance Tester is developed and manufactured according to the combustion test requirements specified in Clause 6.10 of JG 3050-1998.
The equipment is available in intelligent and standard versions according to different customer requirements.
The test selects different flame application times according to the thickness of the material to determine the self-extinguishing performance of the material.
It is suitable for self-extinguishing tests of insulating electrical conduits and fittings used in buildings.
Product Features
- Combustion chamber with painted finish for an attractive and corrosion-resistant appearance; size 650 mm x 400 mm x 1100 mm.
- All fixtures are made of 304 stainless steel for corrosion resistance.
- Imported standard burner with 9 mm inner nozzle diameter.
- Burner angle adjustable between 90 degrees and 45 degrees.
- Flame height: horizontal 100 mm and blue flame 50 mm.
- Imported brand pressure gauge and regulating valve provide more stable gas pressure.
- Imported needle valve precisely controls flame height for better flame stability.
- Pulse high-voltage electronic automatic ignition and automatic flameout.
- Timing button works with PLC to automatically record and store burning time.
- Test time and flame application time can be set on the touch screen.
- Automatic timer records test time and stores it in the system for report inquiry.
- Top-mounted exhaust fan removes waste gas generated after the test; exhaust duct and gas supply to be prepared by the customer.
- Equipped with a 304 stainless steel flame height gauge.
Included Accessories
- 304 stainless steel flame height gauge.
- 2 pipe clamps.
- Product manual.
- Certificate of conformity.
- Wooden packaging for safe and reliable transportation.
Technical Summary
|
Parameter |
Value |
|
Combustion Chamber |
Painted finish, corrosion-resistant, size 650 mm x 400 mm x 1100 mm |
|
Fixtures |
All fixtures are made of 304 stainless steel |
|
Burner |
Imported standard burner with 9 mm inner nozzle diameter |
|
Burner Angle |
Adjustable between 90 degrees and 45 degrees |
|
Flame Height |
Horizontal 100 mm; blue flame 50 mm |
|
Pressure Control |
Imported brand pressure gauge and regulating valve for stable gas pressure |
|
Needle Valve |
Imported needle valve for precise flame height control |
|
Ignition |
Pulse high-voltage electronic automatic ignition and automatic flameout |
|
Timing Function |
Timer button works with PLC to automatically record and store burning time |
|
Touch Screen |
Test time and flame application time can be set on the touch screen |
|
Data Storage |
Automatic timer records test time and stores reports for inquiry |
|
Exhaust Fan |
Top-mounted exhaust fan removes waste gas after the test |
|
Flame Gauge |
Equipped with 304 stainless steel flame height gauge |
|
Included Accessories |
304 stainless steel flame height gauge, 2 pipe clamps, product manual, certificate of conformity, wooden transport packaging |
