Textile 45° Flammability Tester

TESTech Instrument (Suzhou) Technologies is one of the leading manufacturers and suppliers of textile 45° flammability tester in China. Welcome to wholesale premium test equipment at competitive price from our factory. If you have any enquiry about quotation, please feel free to email us.

This tester is designed and manufactured according to the latest GB/T 14645 standard. It is suitable for determining the damage area and damage length of textile fabrics when burned at a 45-degree angle, or for measuring the number of flame contacts when thermal melting reaches a specified length.

It can also be used to assess whether flame-retardant materials comply with relevant fire performance execution standards by measuring afterglow and complete combustion characteristics of specimens mounted at a 45-degree angle.

• Painted sheet-metal enclosure with attractive appearance, corrosion resistance, and durability.
• Heat-resistant glass door for convenient observation of the internal test status.
• All internal tooling is made of stainless steel.
• Power switch for supplying or cutting off power.
• Start switch for beginning the test.
• Six ventilation holes are arranged on the top and along the upper sides of the cabinet.
• Different specimen holders are required for different tests.
• Imported flow regulation valve for precise flame height control.
• Imported pressure gauge and pressure regulating valve.

• Needle valve rotameter regulates flame height; flame height 45 +/- 2 mm.
• Full combustion time is displayed by the counter, with 0.1 s resolution.
• Afterglow time is displayed by the counter, with 0.1 s resolution.
• Flame spread time is set as the specimen ignition time.
• Reset switch sets the counter back to zero.
• Temperature display range and accuracy: 0 to 90 +/- 1 C.
• Imported pressure gauge and pressure regulator display gas pressure.
• Complete combustion stop switch is used to stop the afterglow timing.
• Afterglow stop switch is used to stop the complete combustion timing.
• PLC plus touch-screen control system for more automated testing.
• Planimeter is optional.

• Specimen holder is positioned at 45 degrees inside the chamber.
• Timer accuracy 0.1 s with automatic timing.
• Counter automatically records the number of flame contacts.
• Specimen holder is made from 0.5 mm hard stainless steel wire wound into a helical coil with inner diameter 10 mm.
• Gas burner without air inlet can use butane or propane gas; gas outlet 0.2 mm and flame port 6.4 mm.
• Gas flow range 0 to 1000 ml/min.
• Electronic ignition; timer automatically times with 0.1 s resolution and timing reminder function.
• PLC plus touch-screen control system for more automated testing.
